Sample bags
Applications
Sauces & Condiments
Tomato sauce, ketchup, chili sauce, hot sauce, seasoning sauce, barbecue sauce, salad dressing, and other viscous food sauces.
Cooking Oils & Liquid Foods
Cooking oil, olive oil, edible oil blends, vinegar-based products, and other free-flowing liquid food products.
Juice & Beverage Products
Fruit juice, beverage concentrates, flavored drinks, syrup solutions, and other pumpable liquid products.
Dairy & Cream Products
Butter, cream products, dairy sauces, dessert creams, and other semi-liquid food products.
Paste & Viscous Products
Jam, honey, thick sauces, paste products, seasoning pastes, and other products requiring piston pump filling.
The piston pump filling system can be configured according to product viscosity, filling volume, particle content, flow characteristics, and packaging requirements.
Features
Piston Pump Filling System
The piston pump provides accurate volumetric filling for liquid and viscous products, making it suitable for sauces, oils, creams, and paste products with different flow characteristics.
Automatic VFFS Packaging Process
Integrates film forming, product filling, heat sealing, cutting, and finished bag discharge into one continuous packaging process.
Accurate Liquid & Paste Dosing
The piston filling system provides stable filling volume control and can be adjusted according to different package sizes and product requirements.
Wide Product Compatibility
Suitable for low-viscosity liquids, semi-liquid foods, and high-viscosity pastes including sauces, oils, juices, ketchup, butter, and seasoning products.
Clean Filling Performance
The filling nozzle design helps reduce dripping and product residue around the sealing area, improving package appearance and sealing reliability.
Flexible Bag Formats
Supports different VFFS bag styles according to machine configuration, including pillow bags, gusset bags, and other roll-film formed packages.
Adjustable Filling Parameters
Filling volume, sealing temperature, bag length, and machine speed can be adjusted according to product characteristics and packaging requirements.
Auxiliary Equipment
Liquid Pump
Conveyor Pipe
Out-put Conveyor
Parameters
| Item | Specification |
| Model | FT-630B-50 |
| Number of Lanes | 6/8 Lanes |
| Filling Method | Piston pump |
| Bag Making Speed | 20-80 Bags/Min |
| Film Width | Max. 600mm |
| Bag Width & Length | 20-50mm, 40-200mm |
| Sealing & Cutting Type | Round Corner Cut / Flat Cut / Serrated Cut |
| Power Supply | 220V 1P 50 or 60Hz / 11KW, 12KW |
| Air Consumption | 65-85L/min (0.6-0.8MPa) |
| Overall Dimensions | Refer to Layout Drawing |
| Film Thickness | 0.06-0.1mm |
| Coding Method | Optional: Laser Coding, Hot Stamp Printing, Inkjet Printing, Color Ribbon Printing, Embossing |
| Film Material | Pure Aluminum Foil Laminated Film, Aluminum-Plastic Laminated Film, Other Composite Films |
