Video
Sample bags
Applications
This Mixed Granule Premade Pouch Packaging Machine is designed for products requiring multiple ingredients or different granular materials to be combined and packed into the same premade pouch.
Mixed Nuts Packaging
Mixed nuts, trail mix, roasted nuts, almonds, peanuts, cashews, pistachios, and customized nut combinations.
Grain & Cereal Mixes
Mixed grains, breakfast cereals, oatmeal blends, beans, seeds, and other multi-component grain products.
Snack Mix Products
Snack mixes, popcorn combinations, candy mixes, chocolate snacks, and other products containing multiple ingredients.
Healthy Food Blends
Dried fruit mixes, nut and fruit combinations, nutritional mixes, and functional food blends requiring different ingredient ratios.
Pet Food & Treat Mixes
Mixed pet treats, dry pet food combinations, and other granular products requiring multiple feeding components.
The feeding system can be configured according to the number of ingredients, product characteristics, mixing ratio, target weight, and required packaging format.
Features
Multi-Feeding System for Mixed Products
Equipped with multiple feeding units, allowing different granules or ingredients to be supplied separately and combined into one pouch according to the required recipe.
Customized Product Mixing
Suitable for mixed nuts, grain blends, snack combinations, and other products requiring flexible ingredient combinations before packaging.
Automatic Premade Pouch Packaging
Automatically completes pouch feeding, pouch opening, product filling, sealing, and finished pouch discharge for continuous packaging production.
Flexible Ingredient Configuration
The number of feeding units can be customized according to the number of ingredients, product types, and required mixing combinations.
Accurate Product Portioning
The weighing or feeding system provides controlled product dosing to maintain consistent package weight and ingredient distribution.
Suitable for Various Granular Products
Handles free-flowing granular products with different sizes, shapes, and densities, including nuts, grains, seeds, snacks, and dried foods.
Multiple Premade Pouch Formats
Auxiliary Equipment
Elevator
Bowl Elevator
Multi-heads Weigher
Rotary Table
Output Conveyor
Parameters
| Model | FT-8200 | FT-8230 | FT-8300 |
| Packing speed | 30-60bag/min（speed is depends on the product natures） | MAX 60 bags/min, depends on the quality of the packaging film, packaging materials packaging weight etc. | 5-60 bags/min, depend on the measuring equipment, materials, product’s weight & packing film’ material etc. |
| Bag size | W：70-200mm, L: ≤350mm | (L)100-350mm (W)90-230mm | (L)150-450mm (W) 180-300mm |
| Bag type | 3-side, four edge-sealing bag, self-reliance bag, handbag, spout bags, zipper bag, compound bag, etc | Pre-made bags, Stand-up bag, four-side sealed bag, three-side sealed bag, special-shaped bag | Premade pouch, 3 side-seal pouch with zipper or without zipper |
| Weighing range | 10g-1kg | 10g-1kg | 50g-3kg |
| Measurement accuracy | ≤±0.5~1%, depending on the measuring equipment & materials. | ≤±0.5~1%, depending on the measuring equipment & materials. | ≤±0.5~1%, depending on the measuring equipment & materials. |
| Maximum bag width | 200mm | 230mm | 320mm |
| Gas consumption | 0.8Mpa 0.3m3/min (Supply by user) | 0.8Mpa 0.3m3/min (Supply by user) | 0.8Mpa, 0.3m3/min(supply by user) |
| Total Powder/Voltage | 4.5KW 380V 50/60Hz | 4.5KW 380V 50/60Hz | 4.5KW 380V 50/60Hz |
| Air compressor | Not less than 1CBM | Not less than 1CBM | Not less than 1CBM |
| Dimension | 1900mm X 1300mm X 1500mm（L*W*H） | L2070*W1630*H1460 | (L)2150 * (W)1835 * (H)1500mm |
| Machine Weight | 1500kg | 1500kg | 1600kg |
| Working steps | Bag delivering→ coding →opening →filling 1 →filling 2→ auxiliary→ exhaust →heat sealing→ forming and discharge | Giving bag→Coding→Opening bag(or Open zipper bag)→Filling→ Auxiliary→Exhaust→Heat sealing→Forming and output products. | Giving bag→Coding→Opening bag(or Open zipper bag)→Filling→ Auxiliary→Exhaust→Heat sealing→Forming and output products. |
PLAN YOUR PROJECT
Tell us what you need to pack.
Share your product, bag type, filling weight and target output. We’ll help you identify a suitable configuration.
