This Multihead Weigher Doypack Packing Machine is designed for free-flowing granular and irregular products requiring accurate weight-based filling into premade Doypack pouches.
Nuts & Nut Mixes
Almonds, peanuts, cashews, pistachios, walnuts, mixed nuts, roasted nuts, and trail mix products.
Snack Foods
Potato chips, crackers, popcorn, puffed snacks, cookies, candies, chocolate pieces, and other snack products.
Dried Fruits
Raisins, dried figs, dried cranberries, dried mango, freeze-dried fruits, and other dehydrated fruit products.
Seeds & Grains
Sunflower seeds, pumpkin seeds, rice, beans, cereal products, and mixed grain products.
Pet Food & Treats
Dry pet food, pet snacks, freeze-dried pet treats, and other granular pet products.
The multihead weighing system can be configured according to product size, shape, bulk density, target weight, and required production capacity.
Features
High Precision Multihead Weighing
The multihead weigher uses intelligent combination calculation to achieve fast and accurate weighing for nuts, snacks, dried fruits, and other granular products.
Automatic Doypack Packaging
Integrates pouch feeding, pouch opening, product filling, sealing, and finished pouch discharge into one automatic packaging process.
Accurate Weight-Based Filling
Provides consistent package weights while reducing product giveaway through optimized combination weighing technology.
Designed for Nuts & Snack Products
Suitable for irregular, fragile, and free-flowing products requiring gentle handling and precise portioning.
Flexible Product Feeding
The feeding system can be customized according to product characteristics, including size, shape, fragility, and flow behavior.
Multiple Doypack Formats
Supports different premade pouch styles including stand-up pouches, zipper pouches, flat pouches, and other compatible pouch types.
Gentle Product Handling
Optimized product transfer design helps reduce impact and protect fragile snacks, chips, dried fruits, and delicate products.
Fast Product Changeover
Stored product parameters allow convenient adjustment between different products and package weights.
Auxiliary Equipment
Vibration Feeder
Z Type Bucket Conveyor
Multi-heads Weigher
Supporting Platform
Pre-made Pouch Packing Machine
Out-put Conveyor
Parameters
| Model | FT-8300 |
| Packing speed | 5-60 bags/min, depend on the measuring equipment, materials, product’s weight & packing film’ material etc. |
| Bag size | (L)150-450mm (W) 180-300mm |
| Bag type | Premade pouch, 3 side-seal pouch with zipper or without zipper |
| Weighing range | 50g-3kg |
| Measurement accuracy | ≤±0.5~1%, depending on the measuring equipment & materials. |
| Maximum bag width | 320mm |
| Gas consumption | 0.8Mpa, 0.3m3/min(supply by user) |
| Total Powder/Voltage | 4.5KW 380V 50/60Hz |
| Air compressor | Not less than 1CBM |
| Dimension | (L)2150 * (W)1835 * (H)1500mm |
| Machine Weight | 1600kg |
| Working steps | Giving bag→Coding→Opening bag(or Open zipper bag)→Filling→ Auxiliary→Exhaust→Heat sealing→Forming and output products. |
