parameters
| Model | FT-8230 |
| Packing speed | MAX 60 bags/min, depends on the quality of the packaging film, packaging materials packaging weight etc. |
| Bag size | (L)100-350mm (W)90-230mm |
| Bag type | Pre-made bags, Stand-up bag, four-side sealed bag, three-side sealed bag, special-shaped bag |
| Weighing range | 10g-1kg |
| Measurement accuracy | ≤±0.5~1%, depending on the measuring equipment & materials. |
| Maximum bag width | 230mm |
| Gas consumption | 0.8Mpa 0.3m3/min (Supply by user) |
| Total Powder/Voltage | 4.5KW 380V 50/60Hz |
| Air compressor | Not less than 1CBM |
| Dimension | L2070*W1630*H1460 |
| Machine Weight | 1500kg |
Applications
This Pet Treat Rotary Premade Pouch Packaging Machine is designed for automatic packaging of dry pet food products, pet snacks, and irregular solid treats requiring accurate filling into premade pouches.
Pet Treats
Dog treats, cat treats, training snacks, dental treats, reward treats, and other retail pet snack products.
Freeze-Dried Pet Food
Freeze-dried meat treats, freeze-dried chicken, freeze-dried fish, freeze-dried cubes, and other lightweight irregular pet products.
Dry Pet Food
Dry cat food, dog food, pet kibble, and other granular pet food products suitable for weight-based filling.
Meat-Based Pet Snacks
Dried meat strips, jerky-style pet treats, meat chunks, and other processed animal snacks.
Mixed Pet Treat Products
Pet treat combinations, mixed snack packs, and products containing multiple shapes or ingredients.
The feeding and filling system can be configured according to product size, shape, fragility, bulk density, target weight, and required production capacity.
Video
WORKING STEPS
Giving bag→ coding →Opening bag(or Open zipper bag) →Filling 1 →filling 2→ Auxiliary→ Exhaust →Heat sealing→ Forming and output products
AUXILIARY Equipment
- Multihead combination weigher
- Finished conveyor
- Slope Elevator
- Supporting Platform
FEATURES
Rotary Premade Pouch Packaging System
Automatically completes pouch feeding, pouch opening, product filling, sealing, and finished pouch discharge in one integrated packaging process.
Designed for Pet Treat Products
Suitable for dry pet food, freeze-dried treats, jerky snacks, and irregular pet products requiring gentle handling and accurate portioning.
Flexible Feeding & Filling Solutions
The feeding system can be customized according to product characteristics, including weighing, counting, volumetric feeding, or other customized filling methods.
Accurate Portion Control
Optional multihead weighing or other dosing systems provide consistent package weights and reduce product giveaway.
Gentle Product Handling
Optimized product transfer helps reduce damage to fragile treats such as freeze-dried products and delicate pet snacks.
Multiple Premade Pouch Formats
Supports stand-up pouches, zipper pouches, flat pouches, and other compatible premade bag styles according to packaging requirements.
Stable Pouch Opening & Sealing
Precise pouch positioning and adjustable sealing parameters ensure reliable pouch handling and consistent sealing performance.
SAMPLE BAGS
PLAN YOUR PROJECT
Tell us what you need to pack.
Share your product, bag type, filling weight and target output. We’ll help you identify a suitable configuration.
