Video
SAMple bags
Applications
- Protein Powder & Fitness Supplements: Whey protein powder, mass gainer powder, casein powder and other fitness protein powder for bottle filling packing.
- Nutritional Meal Powders: Meal replacement powder, collagen peptide powder, probiotic powder and vitamin nutritional powder products.
- Solid Beverage Powders: Various fine solid beverage powder with good flowability for automatic auger filling.
- Food Fine Powder Ingredients: Milk powder, cocoa powder, matcha powder and other food powder materials.
- Healthcare Powder Products: Other free-flowing fine powder requiring high-precision bottle filling and capping.
The auger filling system can be configured according to product characteristics, filling weight, powder fluidity, bottle dimensions, dust control requirements, and required production capacity.
working steps
bottle unscrambling → bottle feeding → auger powder filling → capping → induction sealing → coding → finished bottle output
FEATURES
- Equipped with servo auger dosing system, capable of packing various fine powder products.
- Compatible with multiple bottle types: PET bottles, glass bottles and plastic jars.
- Easy to operate. With PLC controller, HMI system enables simple operation.
- Easy to adjust filling weight and bottle size on the screen, then the machine will adjust accordingly.
- High automation: automatic bottle sorting, powder filling, capping, sealing and date coding.
- Perfect protection system: if the bottle is not in place, filling and capping will not be triggered to avoid material waste and reduce production cost.
- Product contact parts are made of food grade SUS304 to guarantee sanitation and safety.
- Optimized dust-proof design to prevent fine powder overflow and keep workshop clean.
- Stable auger filling, low energy consumption, high efficiency, clean and long service life.
AUXILIARY Equipment
- Screw Powder Feeder
- Bottle Unscrambler
parameters
Production capacity | 30-40 cans/minute (wide-mouth bottle /can ) |
Adaptable Specifications | The weight can be adjusted via the touchscreen. |
Number of filling heads | Double-headed |
Measurement error | ±≤ 1 % g |
electricity source | 380V |
achievement Rate | 5 KW |
External dimensions | 4000 × 1350 × 2400mm |
Heavy quantity | Approximately 850 kg |
Silo volume | 50L (main), 30L (supplementary) |
PLAN YOUR PROJECT
Tell us what you need to pack.
Share your product, bag type, filling weight and target output. We’ll help you identify a suitable configuration.
