parameters
| Model | FT-8230 |
| Packing speed | Max 60 bags/min, depend on the measuring equipment, materials, product’s weight & packing film’ material. |
| Accuracy | ≤±0.5~1%, depending on the measuring equipment & materials. |
| Bag size | (L)100-350mm (W) 90–230mm |
| Filling Volume | 10g-1kg |
| Bag type | Premade bag: 3/4-side-seal pouch, Zipper bag, Stand-up pouch, four-edge-sealing bag, special bag etc. |
| Air consumption | 0.8Mpa 0.3m3/min(supply by user) |
| Power | 4.5KW 380V 50/60Hz |
Applications
With different kinds of Auxiliary device, the packaging machine can handle different kinds of products
1. Nuts and roasted seeds: sunflower seeds, peanuts, almonds, pistachios, walnut kernels, pine nuts, etc.
2. Snacks: candy, chocolate, puffed snacks, potato chips, edamame, mixed nuts, etc.
3. Grains and legumes: mung beans, soybeans, cereals, rice, seeds, etc.
4.Rice strip rice flour products: rice noodles, vermicelli, thick rice noodles, dried rice sticks, rice pasta and other rice-made food
Video
working steps
Bag Picking → Bag Conveying → Bag Opening → Rice Noodle Filling → Material Shaking → First Heat Sealing → Second Heat Sealing → Finished Product Output
AUXILIARY Equipment
- Rotary Premade Pouch Packing Machine
FEATURES
- Capable of working with different kinds of dosing system, capable of packing a wide range of products.
- Capable of working with a range of pouches.
- Easy to operate, With PLC controller, HMI system makes easy operation.
- One step of changing bag size on screen, then the machine will do the adjustment accordingly.
- Full automatically finish all steps like feeding, bag picking, filling, closing, sealing, date coding.
- Perfect prevention system: when the bag is not opened or not opened completely, it will be non-filling and non-sealing, so the bags can be reused and the product is not wasted thus save the production cost.
- The product contact parts are made of food grad SUS304 to ensure sanitation and safety.
- High quality plastic bearings, no need to oil, no contamination.
- Vacuum generator, low consumption, high efficiency, easy to clean, and longer useful life.
SAMple bags
PLAN YOUR PROJECT
Tell us what you need to pack.
Share your product, bag type, filling weight and target output. We’ll help you identify a suitable configuration.
