Applications
The Zipper Pouch Packing Machine is widely used for automatic packaging of granular and solid products into premade zipper pouches.
Fruit Products:
Freeze dried fruits, dried fruits, fruit chips, berries, raisins, and other dehydrated fruit products.
Snack Products:
Nuts, peanuts, candies, chocolate, cookies, chips, and snack foods.
Grain & Seed Products:
Seeds, cereals, grains, beans, and other free-flowing materials.
Other Food Products:
Tea, coffee beans, pet treats, and similar products requiring convenient resealable pouch packaging.
The filling system can be customized according to product characteristics, filling weight, pouch size, and production capacity requirements.
Features
1. Automatic premade pouch packing machine with 4 head linear weigher system, suitable for accurate weighing and packaging of granular products.
2. Equipped with zipper pouch opening, filling and sealing functions for efficient automatic packaging.
3. The machine integrates automatic bag feeding, bag opening, weighing filling, sealing and finished bag output.
4. Bag Types: Suitable for zipper bags, stand up pouches, flat bags, and other premade pouch types.
5. The 4 head linear weigher system provides stable and precise weighing performance for different granular products.
6. Made of high-quality stainless steel, meeting food hygiene and safety standards.
Auxiliary Equipment
Z Type Bucket Elevator
4 Head Linear Weigher (3L)
Zipper Pouch Opening System
Out-put Conveyor
Parameters
| Bag Material | Multilayer Composite Premade Bag (e.g.: PET/PE); |
| 2. Bag Type | 3 Side Seal Bag, Stand-up Bag; |
| 3. Upgradable Bag Type | Gusset Bag, Zipper Bag, Flat Bottom Pouch (Need additional purchase of functional device); |
| 4. Size Range | 100m≤W≤300mm |
| 100mm≤L≤300mm | |
| 5. Speed | 0~15bags/min; |
| 6. Sealing Type | Straight grain, pitch is 1mm (Optional reticulate); |
| 7. Sealing Width | 10mm (5--20mm can be customized); |
| 8. Voltage | 220V, Single-phase, 50/60HZ, 1.2KW; |
| 9. Air Pressure | 0.65Mpa; |
| 10. Air Consumption | 0.3m³/min (Standard machine, no additional function); |
| 11. Body Dimension | 1770*600*1230mm; |
| 12. Packing Dimension | 1860*710*1550mm (Export non-fumigation wooden case). |
