This Activated Carbon Powder Packaging Machine is intended for fine industrial and functional powders that require controlled auger dosing and reliable premade pouch packaging.
Activated Carbon & Adsorbent Powders:
Activated carbon powder, charcoal powder, adsorption media powders, deodorizing powders, and other carbon-based materials.
Filtration & Treatment Powders:
Selected water-treatment powders, filtration media powders, purification materials, and other dry functional powders with similar flow characteristics.
Industrial Fine Powders:
Mineral powders, pigment powders, graphite powder, ceramic powders, and other fine dry materials suitable for screw auger filling.
The auger filling system can be configured according to powder bulk density, flowability, particle size, target filling weight, and dust characteristics. For dusty materials, optional dust extraction and bag-mouth cleaning systems can be added to reduce powder accumulation around the sealing area.
Features
1.Designed for activated carbon powder and fine powder materials, providing clean, accurate, and efficient filling performance.
2.Automatic rotary pouch packaging system with high-speed bag feeding, opening, filling, sealing, and finished pouch discharge.
3.Compatible with various premade pouches, including Stand-up Pouches, Zipper Pouches, and other customized pouch styles.
4.Equipped with a precision auger filling system, ensuring consistent filling volume and minimizing powder leakage.
5.Intelligent PLC control system with touchscreen operation allows easy adjustment of filling parameters and packaging settings.
6.Independent sealing station provides stable heat sealing and improves package appearance and airtightness.
7.Made of food-grade 304 stainless steel, suitable for clean production environments and easy maintenance.
8.Flexible design supports different pouch sizes and powder products, offering a reliable packaging solution.
Auxiliary Equipment
Check weigher
Metal Detector
Rotary Table
Nitrogen Generator
Air Compressor
Air Storage Tank
Parameters
| Model | FT-8300 |
| Packing speed | 5-60 bags/min, depend on the measuring equipment, materials, product’s weight & packing film’ material etc. |
| Bag size | (L)150-450mm (W) 180-300mm |
| Bag type | Premade pouch, 3 side-seal pouch with zipper or without zipper |
| Weighing range | 50g-3kg |
| Measurement accuracy | ≤±0.5~1%, depending on the measuring equipment & materials. |
| Maximum bag width | 320mm |
| Gas consumption | 0.8Mpa, 0.3m3/min(supply by user) |
| Total Powder/Voltage | 4.5KW 380V 50/60Hz |
| Air compressor | Not less than 1CBM |
| Dimension | (L)2150 * (W)1835 * (H)1500mm |
| Machine Weight | 1600kg |
| Working steps | Giving bag→Coding→Opening bag(or Open zipper bag)→Filling→ Auxiliary→Exhaust→Heat sealing→Forming and output products. |
