The Automatic Cartoning Machine is widely used for secondary packaging of various food and consumer products into paper cartons.
Bakery Products:
Durian cake, egg yolk pastry, cakes, cookies, biscuits, and other bakery products.
Snack Products:
Candy, chocolate, wafer products, chips, and other individually packaged snacks.
Instant Food Products:
Instant noodles, seasoning packs, and other food products requiring carton packaging.
Other Packaged Products:
Household products, daily necessities, and consumer goods suitable for automatic box packing.
The machine can be customized according to product size, carton dimensions, feeding method, sealing requirements, and production capacity.
Features
- The PLC (Iovanadtstmqversulationad electrica components are all sourced from internationally renowned brands.
- It adopts a human-machine interface operating system, parameter memory, and menu management.
- It includes automatic detection of empty packages and removal of paper boxes with missing packaging materials and instructions.
- It featureshanicovertwdiayalrmionsd finished product counting.
- It delivers stable performance andis easy to operate and understand
Auxiliary Equipment
Hot Melt Glue Unit
Parameters
| Model | FT-60 | FT-60L |
| Cartoning speed | 30-60 cartons/min | 20-45 cartons/min |
| Carton quality requirement | 250-450 g/m² (According to box dimensions) | 250-450 g/m² (According to box dimensions) |
| Carton dimension range (L × W × H) | L: 70-250 mm W: 50-180 mm H: 20-90 mm | L: 120-360 mm W: 50-260 mm H: 20-90 mm |
| Customization | Special size can be customized | Special size can be customized |
| Working pressure (Compressed air) | ≥ 0.6 Mpa | ≥ 0.6 Mpa |
| Air consumption | 20 m³/h | 20 m³/h |
| Power supply | 220V / 50Hz | 220V / 50Hz |
| Motor power | 4.5 kW | 4.5 kW |
| Machine dimensions (L × W × H) | 4528 mm × 1630 mm × 1950 mm | 5630 mm × 1821 mm × 1950 mm |
| Machine weight | 1000 kg | 1200 kg |
