Video
Sample bags
Applications
This Electric Toothbrush Head Packaging Machine is designed for small personal-care components that require automatic orientation, controlled feeding, and individual pouch packaging. The ring feeding system organizes products before pouch loading, reducing manual handling and helping protect finished surfaces during the packaging process.
Electric Toothbrush Accessories:
Electric toothbrush heads, sonic toothbrush replacement heads, children’s toothbrush heads, brush head refill packs, and similar oral-care accessories.
Personal Care Replacement Parts:
Facial cleansing brush heads, electric shaver heads, grooming device attachments, and other small replaceable personal-care components.
Small Precision Components:
Small molded plastic parts and lightweight consumer-product components with similar shapes that can be automatically oriented and transferred by the feeding system.
The feeding system can be configured according to product dimensions, shape, orientation requirements, and the number of pieces required per pouch. Gentle product transfer helps reduce scratching and cosmetic damage before final pouch sealing.
Features
- Designed for small precision products such as electric toothbrush heads, enabling automatic feeding and pouch packaging.
- Ring feeding system automatically arranges and transfers products smoothly, reducing manual loading.
- Suitable for products that are difficult to arrange manually, improving packaging efficiency and consistency.
- Compatible with various pouch types, including Stand-up Pouches, Zipper Pouches, and customized bags.
- Gentle feeding structure protects products from scratches and damage during the packaging process.
- PLC control system with touchscreen interface ensures easy operation and stable performance.
- Compact design with high automation, reliable operation, and low labor requirements.
Auxiliary Equipment
Date Coding Printer
Out-put Conveyor
Nitrogen Generator
Air Compressor
Pre-made Pouch Packing Machine
Parameters
| Model | FT-8200 | FT-8230 |
| Packing speed | 30-60bag/min（speed is depends on the product natures） | MAX 60 bags/min, depends on the quality of the packaging film, packaging materials packaging weight etc. |
| Bag size | W：70-200mm, L: ≤350mm | (L)100-350mm (W)90-230mm |
| Bag type | 3-side, four edge-sealing bag, self-reliance bag, handbag, spout bags, zipper bag, compound bag, etc | Pre-made bags, Stand-up bag, four-side sealed bag, three-side sealed bag, special-shaped bag |
| Weighing range | 10g-1kg | 10g-1kg |
| Measurement accuracy | ≤±0.5~1%, depending on the measuring equipment & materials. | ≤±0.5~1%, depending on the measuring equipment & materials. |
| Maximum bag width | 200mm | 230mm |
| Gas consumption | 0.8Mpa 0.3m3/min (Supply by user) | 0.8Mpa 0.3m3/min (Supply by user) |
| Total Powder/Voltage | 4.5KW 380V 50/60Hz | 4.5KW 380V 50/60Hz |
| Air compressor | Not less than 1CBM | Not less than 1CBM |
| Dimension | 1900mm X 1300mm X 1500mm（L*W*H） | L2070*W1630*H1460 |
| Machine Weight | 1500kg | 1500kg |
| Working steps | Bag delivering→ coding →opening →filling 1 →filling 2→ auxiliary→ exhaust →heat sealing→ forming and discharge | Giving bag→Coding→Opening bag(or Open zipper bag)→Filling→ Auxiliary→Exhaust→Heat sealing→Forming and output products. |
