Video
Sample bags
Applications
This Juice & Beverage Premade Pouch Packaging Machine is designed for free-flowing and pumpable beverage products requiring automatic filling into ready-made pouches.
Fruit Juice & Beverages:
Fruit juice, fruit drinks, vegetable juice, flavored beverages, tea beverages, non-carbonated drinks, and other ready-to-drink liquid products.
Water & Functional Drinks:
Drinking water, flavored water, electrolyte drinks, functional beverages, sports drinks, and other non-carbonated liquid products.
Milk-Based Beverages:
Milk drinks, flavored milk, plant-based beverages, yogurt drinks with suitable flow characteristics, and other pumpable dairy or dairy-alternative beverages.
Liquid Concentrates:
Fruit concentrates, beverage concentrates, drink bases, liquid flavoring products, and other pumpable liquid ingredients.
The filling system can be configured according to product viscosity, filling volume, flow characteristics, and required production capacity. Different premade pouch formats can also be handled according to pouch dimensions and packaging requirements.
Features
Automatic Liquid Filling System
Provides controlled filling for juice, beverages, water, and other pumpable liquid products. The filling system can be selected according to product viscosity, filling volume, and production requirements.
Automatic Premade Pouch Handling
Automatically completes pouch feeding, positioning, opening, liquid filling, sealing, and finished-pouch discharge for continuous beverage packaging production.
Designed for Beverage Packaging
Suitable for fruit juice, tea beverages, drinking water, milk-based drinks, functional beverages, and other non-carbonated liquid products.
Flexible Filling Configuration
Different liquid pumps, filling nozzles, tanks, and product-contact components can be configured according to the characteristics of different beverage products.
Multiple Premade Pouch Formats
Compatible with stand-up pouches, flat pouches, zipper pouches, and other suitable premade pouch formats according to machine configuration.
Clean & Controlled Filling
The filling nozzle and operating parameters can be optimized to reduce dripping and product contamination around the pouch opening, helping maintain a clean sealing area.
Reliable Pouch Sealing
Controlled sealing temperature, pressure, and sealing time provide consistent pouch closure for different compatible packaging materials.
Auxiliary Equipment
Liquid Pump
Paste Pump
Parameters
| Model | FT-8300 |
| Packing speed | 5-60 bags/min, depend on the measuring equipment, materials, product’s weight & packing film’ material etc. |
| Bag size | (L)150-450mm (W) 180-300mm |
| Bag type | Premade pouch, 3 side-seal pouch with zipper or without zipper |
| Weighing range | 50g-3kg |
| Measurement accuracy | ≤±0.5~1%, depending on the measuring equipment & materials. |
| Maximum bag width | 320mm |
| Gas consumption | 0.8Mpa, 0.3m3/min(supply by user) |
| Total Powder/Voltage | 4.5KW 380V 50/60Hz |
| Air compressor | Not less than 1CBM |
| Dimension | (L)2150 * (W)1835 * (H)1500mm |
| Machine Weight | 1600kg |
| Working steps | Giving bag→Coding→Opening bag(or Open zipper bag)→Filling→ Auxiliary→Exhaust→Heat sealing→Forming and output products. |
