This Premade Pouch Powder Packing Machine is particularly suitable for fine, dusty, and non-free-flowing powders that require controlled dosing. The screw auger filling system provides consistent volumetric feeding and helps reduce powder spillage during the filling process.
Typical applications include carrot powder, beetroot powder, spinach powder, pumpkin powder, fruit and vegetable powders, spice blends, seasoning powders, and other fine food ingredients.
For powders with different bulk densities or flow characteristics, the auger filling system can be configured with suitable screw specifications and filling parameters to achieve stable dosing performance. The machine can also accommodate various premade pouch formats, including stand-up pouches, flat pouches, and zipper pouches.
Features
1. Equipped with auger filling system for accurate and stable powder dosing.
2. Integrates automatic pouch loading, opening, filling, sealing, and finished bag output.
3. PLC control system with touch screen interface ensures easy operation.
4. Suitable for stand up pouch, zipper pouch, and three side seal bag.
5. Specially designed for carrot powder, vegetable powder, and other fine powder products.
6. Stainless steel construction meets food hygiene standards.
Auxiliary Equipment
Auger filler
out-put conveyor
Parameters
| Bag Material | Multilayer Composite Premade Bag (e.g.: PET/PE); |
| 2. Bag Type | 3 Side Seal Bag, Stand-up Bag; |
| 3. Upgradable Bag Type | Gusset Bag, Zipper Bag, Flat Bottom Pouch (Need additional purchase of functional device); |
| 4. Size Range | 100m≤W≤300mm |
| 100mm≤L≤300mm | |
| 5. Speed | 0~15bags/min; |
| 6. Sealing Type | Straight grain, pitch is 1mm (Optional reticulate); |
| 7. Sealing Width | 10mm (5--20mm can be customized); |
| 8. Voltage | 220V, Single-phase, 50/60HZ, 1.2KW; |
| 9. Air Pressure | 0.65Mpa; |
| 10. Air Consumption | 0.3m³/min (Standard machine, no additional function); |
| 11. Body Dimension | 1770*600*1230mm; |
| 12. Packing Dimension | 1860*710*1550mm (Export non-fumigation wooden case). |
