Applications
Meat Snack Applications:
Beef jerky, dried beef, dried chicken, pork jerky, meat strips, spicy meat snacks, and other dried meat products.
Dried Fruit & Vegetable Applications:
Dried sweet potato, dried mango, dried banana, dried fruit slices, vegetable chips, and other healthy snack products.
Features
Flexible Solid Product Packaging
Designed for different types of solid products, including Beef jerky,pork jerky, meat strips with various shapes and sizes.
Automatic Premade Pouch Handling
Automatically completes pouch feeding, pouch opening, product filling, sealing, and finished pouch discharge, reducing manual packaging operations.
Multiple Feeding Solutions
The machine can be equipped with different feeding systems according to product characteristics, including counting feeders, weighing systems, vibratory feeders, or manual loading solutions.
Suitable for Irregular Products
Handles products that are difficult to package using traditional automatic filling methods due to different shapes, sizes, or quantities.
Accurate Product Loading
The feeding system can be customized according to product requirements to achieve stable and consistent filling performance.
Multiple Premade Pouch Formats
Compatible with different pouch styles including flat pouches, stand-up pouches, zipper pouches, and other suitable premade bags
Auxiliary Equipment
Date Coding Printer
Out-put Conveyor
Nitrogen Generator
Air Compressor
Pre-made Pouch Packing Machine
Parameters
| Model | FT-8200 | FT-8230 | FT-8300 |
| Packing speed | 30-60bag/min（speed is depends on the product natures） | MAX 60 bags/min, depends on the quality of the packaging film, packaging materials packaging weight etc. | 5-60 bags/min, depend on the measuring equipment, materials, product’s weight & packing film’ material etc. |
| Bag size | W：70-200mm, L: ≤350mm | (L)100-350mm (W)90-230mm | (L)150-450mm (W) 180-300mm |
| Bag type | 3-side, four edge-sealing bag, self-reliance bag, handbag, spout bags, zipper bag, compound bag, etc | Pre-made bags, Stand-up bag, four-side sealed bag, three-side sealed bag, special-shaped bag | Premade pouch, 3 side-seal pouch with zipper or without zipper |
| Weighing range | 10g-1kg | 10g-1kg | 50g-3kg |
| Measurement accuracy | ≤±0.5~1%, depending on the measuring equipment & materials. | ≤±0.5~1%, depending on the measuring equipment & materials. | ≤±0.5~1%, depending on the measuring equipment & materials. |
| Maximum bag width | 200mm | 230mm | 320mm |
| Gas consumption | 0.8Mpa 0.3m3/min (Supply by user) | 0.8Mpa 0.3m3/min (Supply by user) | 0.8Mpa, 0.3m3/min(supply by user) |
| Total Powder/Voltage | 4.5KW 380V 50/60Hz | 4.5KW 380V 50/60Hz | 4.5KW 380V 50/60Hz |
| Air compressor | Not less than 1CBM | Not less than 1CBM | Not less than 1CBM |
| Dimension | 1900mm X 1300mm X 1500mm（L*W*H） | L2070*W1630*H1460 | (L)2150 * (W)1835 * (H)1500mm |
| Machine Weight | 1500kg | 1500kg | 1600kg |
| Working steps | Bag delivering→ coding →opening →filling 1 →filling 2→ auxiliary→ exhaust →heat sealing→ forming and discharge | Giving bag→Coding→Opening bag(or Open zipper bag)→Filling→ Auxiliary→Exhaust→Heat sealing→Forming and output products. | Giving bag→Coding→Opening bag(or Open zipper bag)→Filling→ Auxiliary→Exhaust→Heat sealing→Forming and output products. |
