Parameters
Model | FT-VP42 Packing Machine |
Packing Speed | 10-35 bags / min |
Pouch Size (mm) | L80 - 320, W70 - 200 |
Max. Film Width (mm) | 420mm |
Pouch Thickness (mm) | 0.04 - 0.10 |
Pouch Material | BOPP / CPP, PET / AL / PE etc |
Compress Air | 0.8MPa, 0.3m3/min |
Power | 4.5KW |
voltage | 220V/50HZ |
Unit Size (mm) | 1480*960*1400 |
Unit Weight (kg) | 450kg |
Applications
Biscuits & Cookies: Cookies, mini cookies, sandwich biscuits, wafer biscuits, butter cookies, crackers, and other suitable biscuit products.
Snack Foods: Puffed snacks, rice crackers, corn snacks, crispy snacks, coated snacks, and other solid snack foods.
Nuts: Peanuts, almonds, cashews, pistachios, walnuts, hazelnuts, mixed nuts, and other suitable nut products.
Seeds: Sunflower seeds, pumpkin seeds, melon seeds, mixed seeds, and other free-flowing seed products.
Candy & Chocolate: Hard candy, coated candy, gummies, chocolate pieces, chocolate beans, and other suitable confectionery products.
Grains & Cereals: Rice, millet, beans, corn, cereals, and other free-flowing granular food products.
Pet Food: Dry dog food, cat food, pet treats, and other suitable granular pet food products.
The multihead weighing and gusset bag forming system can be configured according to product size, shape, bulk density, target filling weight, required bag dimensions, and production capacity.
Video
Working steps
Film feeding → Bag forming → Longitudinal sealing (back sealing) → Transverse sealing (bottom sealing) → Cutting and filling → Transverse sealing (sealing + cutting) → Finished product output
Auxiliary Equipment
- Multi heads weigher
- Z type conveyor
Features
Gusset Bag Forming: Special gusset-forming components create side folds in the package, producing a more structured bag shape with increased internal capacity and improved shelf presentation.
Designed for Biscuits & Snacks: Suitable for biscuits, cookies, crackers, nuts, candies, chocolate, seeds, and other suitable solid or granular snack products.
Accurate Multihead Weighing: The multihead weigher automatically calculates weight combinations to provide consistent portions for biscuits, snacks, nuts, candies, and other products.
Automatic Z-Type Feeding: The Z-type conveyor continuously transfers products to the multihead weighing system for automatic production. The current machine is configured with a Multihead Weigher and Z-Type Conveyor.
Automatic VFFS Packaging: Automatically completes roll-film feeding, bag forming, gusset forming, filling, longitudinal sealing, transverse sealing, cutting, and finished-bag discharge.
Improved Bag Capacity: Gusseted sides expand when filled, providing additional internal volume compared with a conventional flat pillow bag of similar face dimensions.
Professional Retail Presentation: Gusset bags provide a fuller and more structured package appearance suitable for biscuits, snacks, nuts, pet food, and other retail products.
High-Quality Heat Sealing: High-precision toothed sealing and independent temperature control provide strong and consistent package seals.
Precise Film Tracking: Color-mark sensors provide accurate positioning of printed packaging film, with the current specification listing accuracy up to ±1 mm.
Intelligent Error Prevention: Communication between the packaging machine and weighing system helps detect empty bags or products that do not meet preset weight requirements.
Sample bags
Optional functions
- Date coder
- Air flushing
- Gusset bag
- Air degassing
